《稳先微》非隔离PF>0.9
《稳先微》非隔离PF>0.9
《稳先微》非隔离LED驱动芯片是适用于85Vac-265Vac全范围输入电压的降压型恒流电源方案，芯片内带有高精度的电流取样电路，同时采用了先进的恒流控制技术，实现高精度的LED恒流输出和优异的线性调整率。芯片工作在电感电流临界模式，系统输出电流不随电感量和LED工作电压的变化而变化，实现优异的负载调整率。
| 》PF>0.9/非隔离 | ||||||||
|
型号 |
工作模式 |
调光 |
功率管 |
应用功率 |
恒流精度 |
封装 |
应用 | |
|
175-264Vac |
90-264Vac | |||||||
|
BCM |
N/A |
外置 |
120V/450mA |
80V/450mA |
±1% |
SOT23-6 |
| |
|
BCM |
N/A |
内置 |
80V/150mA |
50V/150mA |
±1% |
SOP7 |
| |
|
BCM |
N/A |
内置 |
120V/170mA |
80V/170mA |
±1% |
SOP8 |
| |
|
BCM |
N/A |
内置 |
80V/240mA |
60V/240mA |
±1% |
SOP8 |
| |
|
120V/240mA |
80V/240mA |
DIP7 | ||||||
|
BCM |
N/A |
内置 |
70V/240mA |
50V/240mA |
±1% |
SOP7 |
| |
|
80V/240mA |
60V/240mA |
DIP7 | ||||||
|
BCM |
N/A |
内置 |
120V/240mA |
80V/240mA |
±1% |
SOP7 |
| |
|
BCM |
N/A |
内置 |
60V/150mA |
32V/150mA |
±1% |
SOP7 |
| |
|
BCM |
N/A |
内置 |
120V/150mA |
72V/150mA |
±1% |
SOP7 |
| |
|
BCM |
N/A |
内置 |
120V/180mA |
80V/180mA |
±1% |
SOP7 |
| |
|
BCM |
N/A |
内置 |
120V/240mA |
80V/240mA |
±1% |
DIP7 |
| |
|
BCM |
N/A |
内置 |
120V/280mA |
80V/280mA |
±1% |
DIP7 |
| |
|
BCM |
N/A |
内置 |
120V/350mA |
80V/350mA |
±1% |
DIP7 |
| |
